*astTECS PRI Gateway

VoIP PRI Gateways

*astTECS PRI Gateway gives the freedom to connect any enterprise telephony equipment to any internet based next generation network.

With the integrated E1/T1 interfaces and the E-SBC functionality the *astTECS PRI Gateway is the ideal demarcation point for the interface between the enterprise and the network for existing and new technologies.

Using a high precise 5ppm clock and multiple CODECS for voice and fax ensures full ISDN quality. With the integrated header and routi9ng manipulation capabilities a smooth migration for all enterprise equipment and network requirement is guaranteed.

  • Scalable Solution for up to 2 E1/T1 Ports.
  • Demarcation point for ISDN & IP PBXs
  • Full ISDN quality for voice, fax and data.
  • High precise 5ppm clock for full fax and DECT support
  • E-SBC feature set for VoIP-to-VoIP & ISDN-to-VoIP.

FEATURES

Submit Form

SUBMIT
close-link

Call Routing

  • Multiple SIP registrars
  • Multilevel alternative routing
  • Black / White list
  • QoS routing

Call Manipulation

  • Header & number manipulation
  • Codec translation & transrating
  • Overlap / en-block conversion

Advanced

  • Integrated SIP registrar & location Server
  • Integrated E-SBC feature set
  • ISDN supplementary services Conversion
  • Advice of Charge (AoC) generation
  • Full IP routing & firewall capabilities
  • Remote provisioning
  • VPN
  • SNMP

TECHNICAL SPECIFICATION

Architecture Interfaces

Processor

  • Quad-Core 1 Ghz
  • 1 GB RAM
  • 8 GB Flash RAM

Ethernet

  • 10/100 Mbits/s
  • WLAN
  • VLAN

ISDN

  • E1/T1
  • High Precise 5 ppm clock
  • TE/NT mode
  • CRC4/double frame mode

Ethernet

  • 2X10/100 Base-T RJ-45
  • WLAN 802.11b/g/n

ISDN

  • 2XE1 interfaces
  • High Precise 5 ppm clock
  • 100 – 240 VAC, 10W
  • External power Supply
  • Low power consumption (<4W)

Signaling Physical Parameters

ISDN

  • DSS1, Q.931, SS7*
  • ISDN supplementary services

VoIP

  • SIP (RFC 3261 ff)
  • G.711, G.729, G.726
  • Fax: T.38 & G.711
  • Clear Channel
  • Size(WxHxD) : 144X42X94mm
  • Weight : 0.3 KG
  • Material : ABS
  • Mounting : Desktop, Wall Mounting

Environmental Conditions
  • Temperature : -5oC to 40oC
  • Humidity : 5% to 80% (non- condensing)
  • Certifications : EMC, Safety, CE

*astPG 30 PRI Gateway

The *astTECS PRI Gateway *astPG 30 Supports upto 30 concurrent calls. A perfect solution for cost effective call routing.

FEATURES

Submit Form

SUBMIT
close-link
Call Routing

  • Multiple SIP registrars
  • Multilevel alternative routing
  • Black / White list
  • QoS routing

Call Manipulation

  • Header & number manipulation
  • Codec translation & transrating
  • Overlap / en-block conversion
Advanced

  • Integrated SIP registrar & location Server
  • Integrated E-SBC feature set
  • ISDN supplementary services Conversion
  • Advice of Chahrge (AoC) generation
  • Full IP routing & firewall capabilities
  • Remote provisioning
  • VPN
  • SNMP

TECHNICAL SPECIFICATION

Architecture Interfaces
Processor

  • Quad-Core 1 Ghz
  • 1 Gbyte RAM
  • 8 Gbyte Flash RAM

Ethernet

  • 10/100 Mbits/s
  • WLAN
  • VLAN

ISDN

  • E1/T1
  • High Precise 5 ppm clock
  • TE/NT mode
  • CRC4/double frame mode
Ethernet

  • 2X10/100 Base-T RJ-45
  • WLAN 802.11b/g/n

ISDN

  • 2XE1 interfaces
  • High Precise 5 ppm clock
  • 100 – 240 VAC, 10W
  • External power Supply
  • Low power consumption (<4W)

Signaling Physical Parameters
ISDN

  • DSS1, Q.931, SS7*
  • ISDN supplementary services

VoIP

  • SIP (RFC 3261 ff)
  • G.711, G.729, G.726
  • Fax: T.38 & G.711
  • Clear Channel
  • Size(WxHxD) : 144X42X94mm
  • Weight : 0.3 KG
  • Material : ABS
  • Mounting : Desktop, Wall Mounting

Enviromental Conditions
  • Tempratture : -5oC to 40oC
  • Humidity : 5% to 80% (non- condensing)
  • Certifications : EMC, Safety, CE

* – Optional

*astPG 60 PRI Gateway

The *astTECS PRI Gateway *astPG 60 Supports upto 60 concurrent calls. A perfect solution for cost effective call routing.

FEATURES

Submit Form

SUBMIT
close-link
Call Routing

  • Multiple SIP registrars
  • Multilevel alternative routing
  • Black / White list
  • QoS routing

Call Manipulation

  • Header & number manipulation
  • Codec translation & transrating
  • Overlap / en-block conversion
Advanced

  • Integrated SIP registrar & location Server
  • Integrated E-SBC feature set
  • ISDN supplementary services Conversion
  • Advice of Chahrge (AoC) generation
  • Full IP routing & firewall capabilities
  • Remote provisioning
  • VPN
  • SNMP

TECHNICAL SPECIFICATION

Architecture Interfaces
Processor

  • Quad-Core 1 Ghz
  • 1 Gbyte RAM
  • 8 Gbyte Flash RAM

Ethernet

  • 10/100 Mbits/s
  • WLAN
  • VLAN

ISDN

  • E1/T1
  • High Precise 5 ppm clock
  • TE/NT mode
  • CRC4/double frame mode
Ethernet

  • 2X10/100 Base-T RJ-45
  • WLAN 802.11b/g/n

ISDN

  • 2XE1 interfaces
  • High Precise 5 ppm clock
  • 100 – 240 VAC, 10W
  • External power Supply
  • Low power consumption (<4W)

Signaling Physical Parameters
ISDN

  • DSS1, Q.931, SS7*
  • ISDN supplementary services

VoIP

  • SIP (RFC 3261 ff)
  • G.711, G.729, G.726
  • Fax: T.38 & G.711
  • Clear Channel
  • Size(WxHxD) : 144X42X94mm
  • Weight : 0.3 KG
  • Material : ABS
  • Mounting : Desktop, Wall Mounting

Enviromental Conditions
  • Tempratture : -5oC to 40oC
  • Humidity : 5% to 80% (non- condensing)
  • Certifications : EMC, Safety, CE

* – Optional
