The SIP-based analog voice gateway provides voice/fax communication over the IP network (VoIP/FoIP). It links traditional telephony networks to IP networks with conventional telephony devices such as analog phones or fax machines.The highly flexible call routing settings allow the administrator to configure different routes for calls based on the dialed number. Both proxy-based calls and peer-to-peer calls are supported simultaneously. The SIP-based media gateway supports a phonebook to place peer-to-peer calls without going through a VoIP server. This gateway can reduce or eliminate long distance or inter-office phone charges by routing calls over the Internet or any IP network. Corporations can also enjoy the benefits of network consolidation and improved controllability of the telephone system.

Features of our SIP-Based Media Gateway

  • SIP call control protocols

  • 1 Console RS232 (RJ45 connector)

  • 48 FXS port (RJ45 connector)

  • Centralized network management

  • IP configuration through IVR

  • Remote logging through a syslog server
  • Web-based GUI

  • 2 LAN/WAN 10/100//1000 Base-T Ethernet (RJ45 connector)

  • N-way conferencing

  • Echo cancellation

  • Caller ID display & generation

  • Silence suppression

  • Local self-survival mode

  • 12 months Warranty

  • Call forward

Connect Seamlessly!
Discover our easy-to-use SIP based Media Gateway Solution today.

Technical Specifications


Telephony Signalling:
DTMF tone detection/generation, DTMF relay: in-band,RFC 2833 and SIP InfoCall forward: unconditional,no answer & busy

N-way conferencing

Inbuilt-dial planner for simple call routing

Caller ID presentation

SIP Standards:

RFC 3261,RFC 3265,RFC 3515, RFC 3264,

RFC 2782 & RFC 3428.

Voice Quality:

Echo cancellation

Silence suppression(voice activity detection, comfortable noise generation)

Adaptive jitter buffer

Number of Ports:

48 FXS (RJ-45 connector)

2 LAN/WAN 10/100/1000 Base-T ethernet (RJ-45 connector)

1 console(RJ-45 connector)

Network Protocols:

IPv4, IPv6,TCP, UDP, PPPoE, DHCP DNS,

NAT, Telnet, HTTP, FTP, TFTP

Network Features:

IEEE 802.1q VLAN

Firmware Update:

Local file, FTP, TFTP and HTTP

Administration Features:

SNMP

Configuration & Management:

Web-based GUI

Backup & Restore:

Through ethernet interface 1 × RS232, Built-In Command line interface

Console, telnet command line

Centralized network management

IP configuration setting through IVR

Telephony Features:

Hot-line call

Dial plan

Speed dial

Phone book

Access:

Telnet/SSH/HTTP

Voice CODECs:

G.729, G.723.1, G.711 a/u law, G.726

Call Control Protocols:

SIP

Fax:

T.38 fax

LEDs:

1 power, 2 LAN/WAN

Operating Environment:

Operating temperature: 0 – 50ºC

Operating humidity: 10 – 90%

Weight:

2.1kg

Dimensions:

440(W) x 245(D) x 44(H) mm

Power Supply:

Input 48V DC/1.2A
